| GENERAL INFORMATION |
| pitch |
10,16 mm |
| Height |
19 mm |
| Depth |
12.5 mm |
| Dimensional class |
Media |
| Wire section |
2.5 mm² / 14 AWG |
| Clamp opening size |
2.8 x 4 mm |
| Wire stripping |
max 9.5 mm |
| Operating temperature |
-40 ÷ +130 °C |
| ELECTRICAL CHARACTERISTICS |
| Current |
24 A |
| Voltage |
750 V |
| impulse voltage |
3 kV |
| MECHANICAL CHARACTERISTICS |
| Screw |
M3 |
| Recommended torque |
0.8÷0.88 Nm / 7.2÷7.9 in.lbs |
| APPROVALS DATA |
|
 |
 |
 |
|
EN 60998-1 |
|
UL 1059 |
| Current |
24 A |
- |
18 A factory / 15 A field |
| Voltage |
750 V |
- |
600 V |
| Wire section |
2.5 mm² |
- |
14 AWG |
| Torque |
0.8 Nm |
- |
4.5 Lb-in |
| FILE |
CA02.00599 |
- |
E178356 |
| MATERIALS |
| Housing |
PA - UL 94 V0 |
| Screw |
Galvanized steel |
| Clamp | Nickel-plated copper alloy |
| Terminal |
Tin-plated copper alloy |
| SCIP Number | 4857c4e6-479f-4765-acd0-7361f5cc6333 |
| COLOURS |
|
Standard |
On request |
 |
 |
| POLES | NAME | 3D FILE | | 1 | MVSP251-10,16-V | File not available for this product | | 2 | MVSP252-10,16-V | File not available for this product |
|
| DIMENSIONAL IMAGE |
 |
