| GENERAL INFORMATION |
| pitch |
3,5 mm |
| Height |
12.6 mm |
| Depth |
8.2 mm |
| Dimensional class |
Bassa |
| Wire section |
1.5 mm² / 16 AWG |
| Clamp opening size |
1.8 x 2.6 mm |
| Wire stripping |
max 6 mm |
| Operating temperature |
-40 ÷ +130 °C |
| ELECTRICAL CHARACTERISTICS |
| Current |
13,5 A |
| Voltage |
130 V |
| impulse voltage |
1.25 kV |
| MECHANICAL CHARACTERISTICS |
| Screw |
M2 |
| Recommended torque |
0.2÷0.22 Nm / 1.8÷2 in.lbs |
| APPROVALS DATA |
|
 |
 |
 |
|
EN 60998-1 |
|
UL 1059 |
| Current |
17.5 A |
- |
12 A factory / 10 A field |
| Voltage |
130 V |
- |
150 V |
| Wire section |
1.5 mm² |
- |
16 AWG |
| Torque |
0.2 Nm |
- |
1.8 Lb-in |
| FILE |
CA02.04718 |
- |
E178356 |
| MATERIALS |
| Housing |
PA - UL 94 V0 |
| Screw |
Galvanized steel |
| Clamp | Tin-plated copper alloy |
| Terminal |
Tin-plated copper alloy |
| SCIP Number | 44bdd228-db28-48a8-9c38-13f7c55006ec |
| COLOURS |
|
Standard |
On request |
 |
 |
| POLES | NAME | 3D FILE | | 2 | MVS132-3,5-H-L | File not available for this product | | 3 | MVS133-3,5-H-L | File not available for this product | | 4 | MVS134-3,5-H-L | File not available for this product | | 5 | MVS135-3,5-H-L | File not available for this product | | 6 | MVS136-3,5-H-L | File not available for this product | | 7 | MVS137-3,5-H-L | File not available for this product | | 8 | MVS138-3,5-H-L | File not available for this product | | 9 | MVS139-3,5-H-L | File not available for this product | | 10 | MVS1310-3,5-H-L | File not available for this product | | 11 | MVS1311-3,5-H-L | File not available for this product | | 12 | MVS1312-3,5-H-L | File not available for this product |
|
| DIMENSIONAL IMAGE |  |
|
