| GENERAL INFORMATION |
| pitch |
15 mm |
| Height |
16.8 mm |
| Depth |
8.9 mm |
| Dimensional class |
Media |
| Wire section |
2.5 mm² / 14 AWG |
| Clamp opening size |
2.8 x 2.7 mm |
| Wire stripping |
max 7 mm |
| Operating temperature |
-40 ÷ +130 °C |
| ELECTRICAL CHARACTERISTICS |
| Current |
16 A |
| Voltage |
750 V |
|
- |
| MECHANICAL CHARACTERISTICS |
| Screw |
M3 |
| Recommended torque |
0.5÷0.55 Nm / 4.5÷4.9 in.lbs |
| APPROVALS DATA |
|
 |
 |
 |
|
EN 60998-1 |
EN 60998-1 |
UL 1059 |
| Current |
16 A |
16 A |
16 A factory / 15 A field |
| Voltage |
750 V |
750 V |
600 V |
| Wire section |
- |
- |
14 AWG |
| Torque |
- |
- |
4.5 Lb-in |
| FILE |
EP149 |
40023956 |
E178356 |
| MATERIALS |
| Housing |
PA - UL 94 V0 |
| Screw |
Galvanized steel |
| Clamp | Nickel-plated copper alloy |
| Terminal |
Tin-plated copper alloy |
| COLOURS |
|
Standard |
On request |
 |
 |
| POLES | NAME | 3D FILE | | 2 | MVE252-15-V-L | File not available for this product |
|
