| GENERAL INFORMATION |
| pitch |
5,08 mm |
| Height |
10.8 mm |
| Depth |
18.7 mm |
| Dimensional class |
n/a |
| Wire section |
- |
| Clamp opening size |
- |
| Wire stripping |
- |
| Operating temperature |
-40 ÷ +130 °C |
| ELECTRICAL CHARACTERISTICS |
| Current |
24 A |
| Voltage |
250 V |
|
- |
| MECHANICAL CHARACTERISTICS |
| Screw |
- |
| Recommended torque |
- |
| APPROVALS DATA |
|
 |
 |
 |
|
|
|
UL 1059 |
| Current |
- |
- |
- |
| Voltage |
- |
- |
300 V |
| Wire section |
- |
- |
- |
| Torque |
- |
- |
- |
| FILE |
- |
- |
E178356 |
| MATERIALS |
| Housing |
PA - UL 94 V0 |
| Screw |
- |
| Clamp | - |
| Terminal |
- |
| COLOURS |
|
Standard |
On request |
 |
 |
| POLES | NAME | 3D FILE | | 02 | PVSF02-5,08-H-D68-1F | File not available for this product |
|
|
